Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125
Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125

Wiseco

SKU: SKU: WISK0166X125

Wiseco Ford Small Block 302 4.125in Bore 1.280in CH -7.50 CC Piston Set - K0166X125

$978.99 USD
<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>
Customers also viewed

Professional Series forged racing pistons from Wiseco are no-expense-spared pistons designed for the serious racers and builders. Packed full of custom-level performance and durability features and provided with premium rings, Professional Series pistons are designed and built for use in heavy to severe duty race builds. Remove your limits with Wiseco's Professional Series.

Features

  • Wiseco Ford Small Block 302 Piston Set, 4.125 in. Bore, 1.280 in. Compression Height, 0.927 in. Pin Diameter, Professional, Set of 8.
  • Ford 302/351 FT -7.5cc, 1.280CH
  • Piston Set, Ford, Small Block 302, 4.125 in. Bore, Professional, Set of 8

Manufacturer's Limited 30 Day Warranty

Specifications

  • Forging Type: Slab Side
  • Piston Quantity: 8
  • Ring Set Included: Yes
  • Top Compression Ring Thickness: 0.047 IN
  • Second Compression Ring Thickness: 0.047 IN
  • Oil Ring Thickness: 3.0 MM
  • Wrist Pin Included: Yes
  • Wrist Pin Material: 5115
  • Wrist Pin Style: Floating
  • Wrist Pin Outer Diameter: 0.927 IN
  • Product Type: Engine Piston Set
  • Engine: Small Block 302
  • Make: Ford
  • Product Series: Professional
  • Bore Diameter: 4.125 IN
  • Stroke: 4.000 IN
  • Rod Length: 6.200 IN
  • Compression Height: 1.280 IN
  • Piston Volume: -7.50 CC
  • Piston Material: 2618
  • Skirt Coating: Yes
