Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135
Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135

Wiseco

SKU: SKU: WISK0035X135

Wiseco Chevy LS 4.135in Bore 1.110in CH -25.00 CC Piston Set - K0035X135

$1,142.99 USD
<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>
Customers also viewed

Professional Series forged racing pistons from Wiseco are no-expense-spared pistons designed for the serious racers and builders. Packed full of custom-level performance and durability features and provided with premium rings, Professional Series pistons are designed and built for use in heavy to severe duty race builds. Remove your limits with Wiseco's Professional Series.

Features

  • Wiseco Chevrolet LS Piston Set, 4.135 in. Bore, 1.110 in. Compression Height, 0.927 in. Pin Diameter, Professional, Set of 8.
  • Chevy LSX -25cc R/DOME 1.110 CH
  • Piston Set, Chevrolet, LS, 4.135 in. Bore, Professional, Set of 8

Manufacturer's Limited 30 Day Warranty

Specifications

  • Product Series: Professional
  • Bore Diameter: 4.135 IN
  • Stroke: 4.000 IN
  • Rod Length: 6.125 IN
  • Compression Height: 1.110 IN
  • Piston Volume: -25.00 CC
  • Piston Material: 2618
  • Skirt Coating: Yes
  • Forging Type: Strutted
  • Piston Quantity: 8
  • Ring Set Included: Yes
  • Top Compression Ring Thickness: 1.2 MM
  • Second Compression Ring Thickness: 1.2 MM
  • Oil Ring Thickness: 2.8 MM
  • Wrist Pin Included: Yes
  • Wrist Pin Material: 5115
  • Wrist Pin Style: Floating
  • Wrist Pin Outer Diameter: 0.927 IN
  • Product Type: Engine Piston Set
  • Engine: LS
  • Make: Chevrolet
