ReadyLift - 4" SST Lift Kit - 2007-2016 Chevy/GMC Silverado/Sierra 1500 (2WD) - 69-3285

4" front / 1.75" rear SST lift kit for 2007-2016 Silverado/Sierra 1500 2WD.

The 69-3285 4.0" SST Lift Kit is a fully bolt-on system that raises the front of the truck 4.0" using powder-coated steel strut extensions that bolt to the top of the factory strut with no irreversible modifications. It significantly increases ground clearance for tires up to 33" on aftermarket wheels while maintaining the factory ride, with roughly 0.5" of rake for towing or hauling. Now includes ultra-strong TCT free-floating, self-lubricating pivot bushings.

Fits: 2007-2013 Chevrolet Silverado / GMC Sierra 1500 6-lug 2WD, and 2014-2016 2WD models with the cast/forged steel OE upper control arm only. Does NOT fit 2014-up models with aluminum or stamped-steel (build code "AVV") upper control arms. Single-cab configuration has not been validated by ReadyLIFT.

Features

• True 4.0" bolt-on lift, no cutting or welding
• Max lift 4.0" front / 1.75" rear
• 100% DOM tubular upper control arms with OEM-style ball joints; retains OEM geometry with no spindle modifications
• TCT free-floating self-lubricating pivot bushings
• 3.0" OEM-style cast iron rear lift blocks with pinion angle correction, axle locating ears and U-bolts
• Steel rear shock extensions retain the factory rear shocks

Tire Fitment

Up to 33" (commonly 33x11.50 on a 9" wheel with +6 offset). 18" - 295/65R18; 20" - 285/60R20; 22" - 285/50R22. Designed for aftermarket wheels with 5.25" backspacing; a wheel spacer (e.g. 10-3485) is required to run factory wheels.

Notes

Not intended for off-road use. Estimated installation time approximately 7.3 hours (excluding alignment). Backed by the ReadyLIFT Limited Lifetime Warranty.
