Manley Small Block Chevrolet 3/8in ARP Custom Age 625+ Cap Screws (Set of 4) - 42321-4

Important excerpt from the ARP catalog regarding proper fastener installation: “The importance of tightening fasteners to their required preload cannot be emphasized enough. If a fastener is not preload cannot be emphasized enough. If a fastener is not tightened properly, the fastener will not apply the required preload on the application it is being used for and may become susceptible to failure. Conversely, if a fastener is over tightened and stretched too much, it becomes susceptible to failure by exceeding it’s maximum yield point.”

Features

• Premium ARP-manufactured rod bolts engineered for high clamp load and reliability
• Precision thread rolling and heat treatment for maximum tensile strength
• Provides consistent preload when installed using recommended stretch method
• Ideal for high-horsepower, high-RPM street and racing applications

Specs

• Manley Connecting Rod Bolt-3/8 ARP CUSTOM AGE 625+ 1.600 UHL ARP625+
• Stretch .0065" to .0075"
• 80-85 w/ARP lube Torque Value w/ARP Lube During Final Assembly at Manley Performance 80 ft/lb
