Edelbrock E-Series Cylinder Head Bolt Kit #85812 is a high-quality replacement set of bolts with washers for use with Chevy W-series big-block 348/409 engines equipped with Performer RPM #60815 and #60819 aluminum heads. This kit contains all necessary bolts and washers to replace the factory bolts for a pair of heads. E-Series bolts have a yield tensile strength of 190,000 PSI for strong and reliable loading with generous filleting throughout to eliminate stress risers. Bolt threads are rolled after heat-treating for superior form and strength, while a small hex head provides extra space for socket clearance in tight situations. E-Series Cylinder Head Bolts have a durable black oxide finish with sealer and come with the distinctive Edelbrock E stamped into the head.
Edelbrock #85812 is a Head Bolt Kit for 1958-65 Big-Block Chevrolet 348/409 "W" Engines with Edelbrock 60809. 60815, & 60819 Performer RPM Cylinder Heads. This kit contains a complete set of Head Bolts & Washers for a pair of heads.
Specifications
| 9 |
Hex |
| 10 |
8740 Chromoly |
| 546 |
Coarse |
| Thread Diameter |
0.4375 IN |
| 2596 |
3.45 IN |
| 3072 |
Yes |
| Finish |
Black Oxide |
| Grade Type |
Performance |
| Quantity |
Kit |
| Length |
(16) 3.45 in, (20) 4.18 IN |
