Bilstein Part # BIL25-331776

Bilstein B8 5165 11.3in Travel Remote Reservoir - Eye/Eye 360/80 - 25-331776

Before you order

Customers also viewed

4.8 on Google967 store reviews
Ships from Buffalo, NYOur U.S. warehouse
Trusted since 2005Enthusiasts behind the counter

Bilstein B8 5165 remote reservoir shock absorbers are designed to be used on custom off-road vehicles in order to achieve the desired ride of your light truck or SUV. These high gas pressure monotube shock absorbers are sold by various lengths and valve rates to accommodate a wide range of uses and custom applications. All B8 5165 shock absorbers come equipped with 5/8 inch eyelets with hour glass bushings on both ends.

The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting, providing a clean, low profile installation. B8 5165 remote reservoir shock absorbers will increase overall durability of your custom vehicle allowing you to conquer the harshest of off-road environments.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions.

  • Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control.

  • Remote reservoir increases shock oil capacity for greater heat dissipation.

Adjustable damping Non-Adjustable
Boot included No
Compression @0.52m/S 755
Finish Zinc Plated
Lower mount type Eye 5/8in
Rebound @0.52m/S 3775
Reservoir Yes
Spring seat included No
Body design Smooth Body (Non-Coilover)
Collapsed length (in) 16.12
Collapsed length (mm) 409.5
Extended length (in) 27.45
Extended length (mm) 697.2
Internal design Monotube
Mount type Eye-to-Eye
Optional reservoir clamp 11-176015
Series B8 5165
Upper mount type Eye 5/8in
Piston diameter 46mm
Stroke/travel length (in) 11.33
Shaft diameter 14mm
Stroke/travel length (mm) 287.8
Part number 25-331776

  • Universal fitment. Check dimensions before ordering.
