Bilstein Part # BIL25-311761

Bilstein B8 5160 Series 00-06 Suburban 1500 Rear Shock Absorber - 25-311761

Before you order

Customers also viewed

4.8 on Google994 store reviews
Ships from Buffalo, NYOur U.S. warehouse
Trusted since 2005Enthusiasts behind the counter

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application.

Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions.

  • Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control.

  • Remote reservoir increases shock oil capacity for greater heat dissipation.

Collapsed length (in) 16.56
Extended length (in) 28.13
Collapsed length (mm) 420.5
Extended length (mm) 714.7
Series B8 5160
Lower mount type Eye 14.4mm
Upper mount type Eye 14.4mm
Internal design Monotube
Boot included No
Spring seat included No
Adjustable damping Non-Adjustable
Body design Smooth Body (Non-Coilover)
Billet reservoir clamp included Yes
Reservoir Yes
Finish Zinc Plated
Piston diameter 46mm
Stroke/travel length (in) 11.57
Shaft diameter 14mm
Stroke/travel length (mm) 293.9
Part number 25-311761

  • Chevrolet Avalanche 1500 2002-2006, Suburban 1500 2000-2006, Tahoe 2000-2006, Dodge Ram 1500 2006-2008, Ram 2500 1994-2010, Ram 3500 1994-2010, GMC Yukon 2000-2006, Yukon XL 1500 2000-2006, Ram 2500 2011-2013, 3500 2011-2012
