Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
46mm monotube design ensures consistent, fade-free performance in all conditions.
Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology.
Adjustable spring seat offers 0-2.75in of lift, depending on the application.
| Collapsed length (in) | 16.05 |
|---|---|
| Extended length (in) | 21.34 |
| Collapsed length (mm) | 407.6 |
| Extended length (mm) | 542.1 |
| Series | B8 5100 (Ride Height Adjustable) |
| Lower mount type | Crossbar |
| Internal design | Monotube |
| Boot included | No |
| Reservoir | No |
| Adjustable damping | Non-Adjustable |
| Body design | Snap Ring Grooved Body (Coilover) |
| Upper mount type | Stem |
| Spring seat included | Yes |
| Finish | Zinc Plated |
| Piston diameter | 46mm |
| Stroke/travel length (mm) | 134.4 |
| Shaft diameter | 18mm |
| Stroke/travel length (in) | 5.29 |
| Part number | 24-336987 |
