Bilstein Part # BIL24-317863

Bilstein 09-13 Ford F150 4WD B6 4600 Series Front 46mm Monotube Shock Absorber - 24-317863

Before you order

Customers also viewed

Trusted since 2005 Questions? Email sales@raptorracing.com

Bilstein B6 4600 shock absorbers are designed as a direct fit upgrade to OE shock absorbers on stock height light trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B6 4600 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B6 4600 shock absorbers are tuned for each specific application to ensure optimal performance is achieved. B6 4600 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Specific tuning for stock height vehicles
  • Uses OEM springs and mounting hardware

  • Series: B6 4600
  • Lower Mount Type: Eye 20.3mm
  • Internal Design: Monotube
  • Boot Included: No
  • Reservoir: No
  • Adjustable Damping: Non-Adjustable
  • Body Design: Smooth Body (Non-coilover)
  • Upper Mount Type: Stem
  • Finish: Yellow Paint
  • Spring Seat Included: Yes
  • Piston Diameter: 46mm
  • Stroke/Travel Length (mm): 120.1
  • Shaft Diameter: 14mm
  • Collapsed Length (in): 16.93
  • Extended Length (in): 21.66
  • Stroke/Travel Length (in): 4.73
  • Collapsed Length (mm): 430.0
  • Extended Length (mm): 550.2

Application

  • Ford F-150 2009-2013
