ACL Opel Family 1.1L-1.6L Race Series - 4B1350H-STD

• Series: ACL Race Series
• Bearing Type: Connecting rod bearing
• Shell Halves: Identical halves
• Bearing Material Code: F781
• Sizes Offered: STD, .025, .25
• Housing Bore (Tunnel) Diameter: 46–46.013 mm (1.811–1.8115 in)
• Journal Diameter: 42.971–42.987 mm (1.6918–1.6924 in)
• Maximum Wall Thickness at Crown: 1.495 mm (0.0589 in)
• Bearing Width (max): 16.63 mm (0.655 in)

Engine Applications

• Daewoo A15MF 1498cc Inline4 DOHC 4v (bore 76 mm, stroke 81.5 mm) — Daewoo Cielo
• Daewoo A15SMS 1498cc Inline4 SOHC 2v (bore 76.5 mm, stroke 81.5 mm) — Daewoo Lanos
• Daewoo A16DMS 1598cc Inline4 DOHC 4v (bore 79 mm, stroke 81.5 mm) — Daewoo Lanos
• Daewoo C16LZ2 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Daewoo G15MF 1498cc Inline4 SOHC 2v (bore 76.5 mm, stroke 81.5 mm) — Daewoo 1.5i, Daewoo Cielo, Daewoo Cielo Load Runner
• Holden X18XE1 1796cc Inline4 DOHC 4v (bore 80.5 mm, stroke 88.2 mm)
• Opel 12NV 1196cc Inline4 SOHC 2v (bore 77.8 mm, stroke 62.9 mm)
• Opel 12NZ 1196cc Inline4 SOHC 2v (bore 72 mm, stroke 73.4 mm)
• Opel 12ST 1196cc Inline4 SOHC 2v (bore 77.8 mm, stroke 62.9 mm)
• Opel 13N 1297cc Inline4 SOHC 2v (bore 75 mm, stroke 73.4 mm)
• Opel 13NB 1297cc Inline4 SOHC 2v (bore 75 mm, stroke 73.4 mm)
• Opel 13S 1297cc Inline4 SOHC 2v (bore 75 mm, stroke 73.4 mm)
• Opel 13SB 1297cc Inline4 SOHC 2v (bore 75 mm, stroke 73.4 mm)
• Opel 14NV 1389cc Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel 14SE 1389cc Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel 16NZR 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel 16SV 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel B16LES 1598cc Inline4 DOHC 4v Turbo (bore 79 mm, stroke 81.5 mm)
• Opel C12NZ 1196cc Inline4 SOHC 2v (bore 72 mm, stroke 73.4 mm)
• Opel C13N 1297cc Inline4 SOHC 2v (bore 75 mm, stroke 73.4 mm)
• Opel C14NZ 1389cc Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel C14SE 1389cc Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel C14SEL 1389cc Inline4 DOHC 4v (bore 77.6 mm, stroke 73.4 mm)
• Opel C16LZ/LZ2 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel C16NZ 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel C16SE 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel C16SEI 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel C16SEL 1598cc Inline4 DOHC 4v (bore 79 mm, stroke 81.5 mm)
• Opel C16XE 1598cc Inline4 DOHC 4v (bore 79 mm, stroke 81.5 mm)
• Opel E16NZ 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel E16SE 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel X12SZ 1196cc Inline4 SOHC 2v (bore 72 mm, stroke 73.4 mm)
• Opel X14NZ 1389 Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel X14SZ 1389cc Inline4 SOHC 2v (bore 77.6 mm, stroke 73.4 mm)
• Opel X14XE 1389cc Inline4 DOHC 4v (bore 77.6 mm, stroke 73.4 mm)
• Opel X16SZ/SZR 1598cc Inline4 SOHC 2v (bore 79 mm, stroke 81.5 mm)
• Opel X16XE/XEL 1598cc Inline4 DOHC 4v (bore 79 mm, stroke 81.5 mm)
• Opel X18XE1 1796cc Inline4 DOHC 4v (bore 80.5 mm, stroke 88.2 mm)
• Opel Y16XE 1598cc Inline4 DOHC 4v (bore 79 mm, stroke 81.5 mm)
• Opel Z14XE 1389cc Inline4 DOHC 4v (bore 77.6 mm, stroke 73.4 mm)
