ACL Nissan 4 CA18/CA20 Standard Size High Performance Rod Bearing Set - 4B1630HX-STD

• Series: ACL Race Series
• Bearing Type: Connecting rod bearing
• Shell Halves: Identical halves
• Bearing Material Code: F781
• Sizes Offered: STD
• Housing Bore (Tunnel) Diameter: 48–48.013 mm (1.8898–1.8903 in)
• Journal Diameter: 44.961–44.974 mm (1.7701–1.7706 in)
• Vertical Oil Clearance: 0.042–0.084 mm (0.0017–0.0033 in)
• Maximum Wall Thickness at Crown: 1.492 mm (0.0587 in)
• Bearing Width (max): 18.6 mm (0.732 in)

Engine Applications

• Nissan CA16 1598cc Inline4 SOHC 8v (bore 77.95 mm, stroke 83.6 mm)
• Nissan CA16DE 1598cc Inline4 DOHC 4v (bore 78 mm, stroke 83.6 mm) — Nissan Exa
• Nissan CA18 1809cc Inline4 SOHC 8v (bore 83 mm, stroke 83.6 mm)
• Nissan CA18DE 1809cc Inline4 DOHC 4v (bore 83 mm, stroke 83.6 mm) — Nissan 180SX S13
• Nissan CA18DET 1809cc Inline4 DOHC 4v Turbo (bore 83 mm, stroke 83.6 mm) — Nissan 180SX S13
• Nissan CA18ET 1809cc Inline4 SOHC 2v Turbo (bore 83 mm, stroke 83.6 mm)
• Nissan CA20E 1974cc Inline4 SOHC 2v (bore 84.5 mm, stroke 88 mm) — Nissan Pintara U12
• Nissan CA20S 1974cc Inline4 SOHC 2v (bore 84.5 mm, stroke 88 mm) — Nissan Bluebird 910 Series III
• Nissan CD17 1680cc Inline4 SOHC 2v Diesel (bore 80 mm, stroke 83.6 mm)
