ACL Chevy V8 LS Gen III/IV Standard Size Main Bearing Set - 5M7299HX-STD

• Series: ACL Race Series
• Bearing Type: Main bearing
• Shell Halves: Upper & lower
• Bearing Material Code: F780
• Sizes Offered: STD
• Housing Bore (Tunnel) Diameter: 69.873–69.887 mm (2.7509–2.7515 in)
• Journal Diameter: 64.993–65.007 mm (2.5588–2.5593 in)
• Maximum Wall Thickness at Crown: 2.417 mm (0.0952 in)
• Bearing Width (max): 20.45 mm (0.805 in)

Engine Applications

• Chevrolet 294ci (4.8L) LR4 Vortec V8 OHV 2v (bore 96 mm, stroke 83 mm)
• Chevrolet 294ci (4.8L) LY2 Vortec V8 OHV 2v (bore 96 mm, stroke 83 mm)
• Chevrolet 325ci (5.3L) Vortec V8 OHV 2v (bore 96 mm, stroke 92 mm)
• Chevrolet 346ci (5.7L) LS1 V8 OHV 2v (bore 99 mm, stroke 92 mm)
• Chevrolet 346ci (5.7L) LS6 V8 OHV 2v (bore 99 mm, stroke 92 mm)
• Chevrolet 364ci (6.0L) LFA Vortec Hybrid V8 OHV 2v (bore 101.6 mm, stroke 92 mm)
• Chevrolet 364ci (6.0L) LS2 V8 OHV 2v (bore 101.6 mm, stroke 92 mm)
• Chevrolet 364ci (6.0L) Vortec V8 OHV 2v (bore 101.6 mm, stroke 92 mm)
• Chevrolet 376ci (6.2L) L99 V8 OHV 2v (bore 103.25 mm, stroke 92 mm)
• Chevrolet 376ci (6.2L) LS3 V8 OHV 2v (bore 103.25 mm, stroke 92 mm)
• Chevrolet 376ci (6.2L) Vortec V8 OHV 2v (bore 103 mm, stroke 92 mm)
• Holden 5.7L Gen III LS1 V8 OHV 2v (bore 99 mm, stroke 92 mm) — Holden Adventra VY II, Holden Adventra VZ, Holden Caprice WH, Holden Caprice WH II, Holden Caprice WK, Holden Statesman WH, Holden Statesman WH II, Holden Statesman WK, Holden Ute VU II, Hold
• Holden 6.0L Gen IV L76 V8 OHV 2v (bore 101.6 mm, stroke 92 mm) — Holden Commodore VZ, Holden Crewman VZ, Holden Ute VZ
• Holden 6.0L Gen IV L98 V8 OHV 2v (bore 101.6 mm, stroke 92 mm) — Holden Commodore VE, Holden Commodore VE II, Holden Ute VE II, Holden Ute VE
• HSV 6.0L Gen IV LS2 V8 OHV 2v (bore 101.6 mm, stroke 92 mm) — HSV Clubsport E Series
• HSV 6.2L Gen IV LS3 V8 OHV 2v (bore 103.25 mm, stroke 92 mm) — HSV Clubsport E Series
