Bilstein 5100 Series 96-02 Toyota 4Runner Rear 46mm Monotube Shock Absorber - 24-249966

Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Patented digressive valving instantly reacts to changing surface conditions
• Vehicle specific tuning

Specifications

• Series: B8 5100
• Collapsed Length (in): 12.91
• Upper Mount Type: Stem
• Adjustable Damping: Non-Adjustable
• Spring Seat Included: No
• Extended Length (in): 20.67
• Extended Length (mm): 525.0
• Piston Diameter: 46mm
• Collapsed Length (mm): 328.0
• Shaft Diameter: 14mm
• Stroke/Travel Length (mm): 200.2
• Stroke/Travel Length (in): 7.88
• Reservoir: No
• Finish: Zinc Plated
• Boot Included: Black Bellows
• Lower Mount Type: Eye 19mm
• Body Design: Smooth Body (Non-Coilover)
• Internal Design: Monotube

Application

• Toyota 4Runner 1996-2002
