Manley Spring Retainer, RET-TI 1.290 7 DEG +.050 LT1 - 23624-16

Manley Valve Spring Retainers are engineered using finite element analysis and CNC machined to exacting tolerances to deliver unmatched strength and performance. These retainers reduce valvetrain mass, improve RPM potential, and ensure superior valve control in the most demanding racing applications.

Features

• Special 6AL-4V titanium for maximum strength
• CAD designed for ultimate reduction in mass without sacrificing strength
• Must use 7 valve locks
• Use Manley P/N 13098 (recommended) or factory Chevrolet LT valve locks
• Sames as 23623 but +.055" more installed height
• Sames as 23628 dimensionally except made of Titanium

Specs

• Use Manley 13091 Valve Locks (LT-1/LT-4/L-98
• Gen I/II SBC)
• Height: +.050 in
• Valve Stem Diameter: 11/32 in
• Weight: 10.0 grams
• For Chevrolet LT1 / LT4 / L98 and must use Manley P/N 13091
• Product Market: Domestic
• Weight: 10
• Stem Diameter: 11/32
• Valve Stem Diameter: 11/32
• Product Type: Engine Valve Spring Retainer Set
• Quantity: 16
• Valve Spring Outer Diameter: 1.295
• Valve Spring Retainer Quantity: 16
• Valve Spring Retainer Series: 7 Degree Titanium
• Valve Spring Retainer Material: 6AL-4V Titanium
• Valve Spring: Manley 221436
• Valve Lock Angle: 7
• Height: +.050
• First Step Diameter: 1.155
• Second Step Diameter: 0.950
• Third Step Diameter: 0.675
• Industry: Automotive
• Out of Stock Message: Call for Availability
• Title: Manley Titanium 7 Degree Valve Spring Retainer - Use with Manley Spring 221436
