Manley Spring Retainer, RET-TI 1.255 7 DEG LT4 - 23601-16

Manley Valve Spring Retainers are engineered using finite element analysis and CNC machined to exacting tolerances to deliver unmatched strength and performance. These retainers reduce valvetrain mass, improve RPM potential, and ensure superior valve control in the most demanding racing applications.

Features

• Special 6AL-4V titanium for maximum strength
• CAD designed for ultimate reduction in mass without sacrificing strength
• Must use 7 valve locks
• Use Manley P/N 13098 (recommended) or factory Chevrolet LT valve locks
• Sames as 23625 but +.045" more installed height

Specs

• Use Manley 13098 or OE Chevrolet LT4 Valve Locks
• Height: +.095 in
• Valve Stem Diameter: 8mm
• Weight: 6.0 grams
• Must use Manley P/N 13098 or factory Chevrolet LS valve locks
• Valve Spring Retainer Series: 7 Degree Titanium
• Valve Spring Retainer Material: 6AL-4V Titanium
• Valve Spring: Manley 221428/221438
• Valve Lock Angle: 7
• Height: Standard
• First Step Diameter: 0.935
• Second Step Diameter: 0.640
• Third Step Diameter: 0.570
• Industry: Automotive
• Out of Stock Message: Call for Availability
• Title: Manley Titanium 7 Degree Valve Spring Retainer Set of 16 - Use with Manley Spring 221428 or 221438 - Chevrolet Gen V LT4
• Prop 65 Yes/No: Yes
• Prop 65 (C, R or CR): CR
• Prop 65 - Short Label: Prop 65 Warning Label.JPG
• Engine Type: ICE
• Make: Chevrolet
• Engine: LT4
• Product Market: Domestic
• Weight: 6
• Stem Diameter: 8.00
