Bilstein 5160 Series 05-16 Ford F-250/F-350 Super Duty Shock Absorber - 25-311785

Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
• Remote reservoir increases shock oil capacity for greater heat dissipation

Specifications

• Collapsed Length (in): 18.03
• Extended Length (in): 31.27
• Extended Length (mm): 794.2
• Series: B8 5160
• Lower Mount Type: Eye 12mm
• Upper Mount Type: Eye 16mm
• Internal Design: Monotube
• Boot Included: No
• Spring Seat Included: No
• Adjustable Damping: Non-Adjustable
• Body Design: Smooth Body (Non-Coilover)
• Billet Reservoir Clamp Included: Yes
• Reservoir: Yes
• Finish: Zinc Plated
• Piston Diameter: 46mm
• Collapsed Length (mm): 458.0
• Stroke/Travel Length (in): 13.24
• Shaft Diameter: 14mm
• Stroke/Travel Length (mm): 336.3

Application

• Ford F-250 Super Duty 2005-2016, F-350 Super Duty 2005-2016
