SKU: SKU: TOY16VBP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note: Not recommended for standard injection.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2800-7500 |
| Power Increase | 12BHP |
| Duration Inlet | 288° |
| Duration Exhaust | 288° |
| Valve Inlet Lift | .353" 8.94mm |
| Valve Exhaust Lift | .351" 8.89mm |
| Timing Inlet | 38 - 70 |
| Timing Exhaust | 70 - 38 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .096" 2.41mm |
| TDC Exhaust Lift | .094" 2.36mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
