SKU: SKU: MITSBP320B
Profile: BP320.
Application: Race.
Unit Type: Blank.
Note: Extra high lift profile. Piper VSSMITS valve springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Race |
| Duration Inlet | 272° |
| Duration Exhaust | 272° |
| Valve Inlet Lift | .472" 12.00mm |
| Valve Exhaust Lift | .472" 12.00mm |
| Timing Inlet | 28 - 64 |
| Timing Exhaust | 63 - 29 |
| Full Inlet Lift | 108° |
| Full Exhaust Lift | 107° |
| TDC Inlet Lift | .050" 1.27mm |
| TDC Exhaust Lift | .053" 1.35mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
