SKU: SKU: BDADA10B
Profile: DA10.
Application: -
Unit Type: Blank.
Download:-
Right click the link and select 'Save link as' to download.
Click link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Race |
| Duration Inlet | 312° |
| Duration Exhaust | 312° |
| Valve Inlet Lift | .400" 10.16mm |
| Valve Exhaust Lift | .400" 10.16mm |
| Timing Inlet | 50 - 82 |
| Timing Exhaust | 82 - 50 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .144" 3.66mm |
| TDC Exhaust Lift | .144" 3.66mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .010" .25mm |
