SKU: SKU: BDABD4B
Profile: BD4.
Application: -
Unit Type: Blank.
Download:-
Right click the link and select 'Save link as' to download.
Click link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Race |
| Duration Inlet | 312° |
| Duration Exhaust | 312° |
| Valve Inlet Lift | .418" 10.61mm |
| Valve Exhaust Lift | .418" 10.61mm |
| Timing Inlet | 54 - 78 |
| Timing Exhaust | 80 - 52 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .153" 3.88mm |
| TDC Exhaust Lift | .153" 3.88mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .010" .25mm |
